HDW-CX100/X
Applications:
Collector, Converter, Remote Terminal
Technical Specification:
-
Hardware
- Processor: AT91RM9200 @ 160MHz
- RAM memory: 32 MB
- Flash memory: 16 MB
- Billing is stored in Flash memory
- Storage area with non-volatile memory: ~ 16 GB
- One X.25 port and one ethernet port
- Serial console port
- Absence of movable components
- Internal real-time clock
- Automatic restart in case of power failure
- External power supply
- Input voltages: 110/220 Vac (optional 48 Vdc)
- Optional: 2 redundant power supplies
- 19 inch rack support
- Size: 28 x 155 x 35 mm
-
Software
- Linux Operating System - Kernel 2.6
- Telnet - Console
- FTP (Server and Client) - File transfer
- SSH - Console and File transfer (SFTP)
- SNMP - Management
- Syslog - Log
- Gzip - Compression
- NTP Client - Automatic clock setting
- HTTP - WEB Server
- Remote set up
-
File Management
- Backup - data files storage management
- File storage is organized in directories named by date
- Automatic file deleting by time interval
- Automatic file deleting by memory space
-
Thermal and reliability characteristics
- Operating environment temperature: 0 ~ 45°C
- Transport environment temperature: -20 ~ +70ºC
- Operating relative humidity: 30% ~ 80%
- MTBF: > 20.000 hours
- MTTR: < 20 minutes
